Single Phase On Grid Solar Inverter RS485 50V Rated Output Power 1kw ~ 5kw

Efficient Higher Revenue

˙150% DC Input Oversizing

˙Wide MPPT voltage range: 50V-550V

˙Max. input current per string: 20A,Compatible with high power modules

Intelligent Simple O&M

˙ Smart I-V Curve Diagnosis Function: locate PV string faults accurately and automatically detect faults

˙ Intelligent Fault Detection: AC side voltage and current waveforms real-time recorded, fast fault location

˙ Support RS485/WiFi/4G: remote monitoring and operation via PC or mobile phones

Reliable Worry Free

IP66 Protection Degree: support outdoor installation

DC & AC Type II SPD: prevent lightning damage

AFCI Function (Optional): when an arc-fault is detected the inverter immediately stops operation

	XG1KTL-S	XG1.5KTL-S	XG2KTL-S	XG2.5KTL-S	XG3KTL-S	XG3.68KTL-S	XG4KTL-S	XG4.2KTL-S	XG5KTL-S
Input (DC)
Max.Input Power	1.5kw	2.25kW	3kW	3.75kW	4.5kW	5.52kw	6kW	6.3kW	7.5kW
Max. Input Voltage	600V
Start Voltage	50V
Rated Input Voltage	360V
MPPT Yoltage Range	50V～550V
Number of MPP Trackers/Stringper MPPT	1/1
Max. Current per MPPT	20A
Max.ShortCircuitCurrentperMPPT	26A
Output (AC)
Max. OutputCurrent	5A	7.5A	10A	12.5A	15A	16A	20A	21A	22.7A
Rated Output Power	1kW	1.5kW	2kW	2.5kW	3kW	3.68kW	4kW	4.2kW	5kW
Max. OutputPower	1.1KVA	1.65KVA	2.2kVA	2.75KVA	3.3KVA	3.68kVA	4.4kVA	4.62KVA	5kVA
Rated Grid Frequency	50Hz/60Hz
Rated Grid Voltage	220Vac/230Vac/240Vac
Power Factor	>0.99(0.8leading~0.8lagging)
THDi	<3%(Rated Power)
Efficiency
Max. Efficiency	97.30%				97.60%		97.80%
European Efficiency	97.00%				97.20%		97.30%
MPPT Efficiency	99.90%
Protection
DC Reverse Polarity Protection	Yes
Anti-islanding Protection	Yes
A C Short Circuit Protection	Yes
Residual Current Monitoring Unit	Yes
nsulation Resistance Monitoring	Yes
Ground Fault Monitoring	Yes
Grid Monitoring	Yes
PyString Monitoring	Yes
Surge Protection	Typell
AFCI Protection	Optional
Communication
Display	LCD/LED+APP
Communication	RS485/WiFi/4G
Standard Compliance
Grid Connection Standards	IEC61727,IEC62116,IEC 60068,IEC61683,VDE-AR-N 4105, EN 50549,AS/NZS 4777,CEI0-21,VDE 0126-1-1/A1VFR 2014, UTE C15-712-1:2013, DEWADRRG,NRS 097-2-1,C10/11,G98/G99
Safety/EMC	IEC62109-1:2010,IEC 62109-2:2011,EN 61000-6-2:2005,EN61000-6-3:2007/A1:2011
General Data
Dimensions(WxHxD)	270×250x130 mm
Neight	5.5kg
Operating Temperature Range	-30°C~+60°C
Cooling Method	Natural
Protection Degree	IP66
Max. Operating Altitude	4000m
Relative Humidity	0~100%
opology	Transformerless
	<1W
Night Power Consumption
