9000W 10000W On Grid Solar Inverter 9900VA 11000VA 230V 400V

Product Categories

Beijing MITSCN Co., Ltd.

Contact Now

Name: 9000W 10000W On Grid Solar Inverter 9900VA 11000VA 230V 400V
Brand: MITSCN
Price: 1 USD

Ask Lasest Price
Brand Name :	MITSCN
Certification :	ISO
Price :	Negotiable
Delivery Time :	5-8 working days
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	100000 Piece/Pieces per Month

Add to Cart

MITPC5000(4kw-15kw)on grid 02

MODEL		PC50-7000TM	PC50-8000TM	PC50-9000TM	PC50-10000TM	PC50-11000TM
OUTPUT (AC)	Rated AC output power	7000W	8000W	9000W	10000W	11000W
	Max.AC apparent power	7700VA	8800VA	9900VA	11000VA	12100VA
	Max.output current	11.1A	12.7A	14.3A	15.9A	17.5A
	Nominal AC Voltage	230V 400V
	AC Voltage range	320-478V
	AC grid frequency range	50±5Hz
		60±5Hz
	Power factor at Rated power	1
	Adjustable displacement power factor	0.8leading. 0.8lagging
	THDi @ Full load & THDI <1%	< 3%
	AC grid connection type	3W+N+PE
INPUT DATA	Max.recommended PV power	8400W	9600W	10800W	12000W	13200W
	Max.DC voltage	1000V
	Start voltage	160V
	Nominal voltage	600V
	MPPT voltage range	200V-1000V
	Max.input current	12.5A 12.5A
	Number of independent MPP trackers / strings per MPP tracker	21
	DC connection	H4 MC4
EFFICIENCY	Max.efficiency	98.4%
	Euro weighted efficiency	98%
	MPPT efficiency	99.5%
	Protection devices	DC reverse polarity protection , Output over current protection, Output overvoltage protection-varistor, Integrated DC switch, Ground fault monitoring, Integrated all-pole sensitive leakage current monitoring unit
GENERAL DATA FEATURES	Dimension(W/H/D)(mm)	500428200
	Weight (kg)	23.2
	Operation temperature range	-25℃ - +60℃ with derating above 45℃
	Noise emission(typical)	≤35dB(A)
	Altitude	3000m
	Self-consumption (night)	< 1W
	Topology	Transformerless
	Cooling concept	Natural
	Environmental protection Rating	Ip65
	Relative humidity	0-100%
FEATURES	AC connection	connector
	Display	LED
	Interfaces:USB/WI-FI/RS485/GPRS	yes/yes/yes/opt
	Warranty	Standard 5 years 10 years (opt.)
	Certificates and approvals	CE IEC62109 EN50549-1
