Name: Mono PType Solar Powered Generator Positive Power Tolerance 1755103830mm
Brand: Mitscn
Price: 1 USD

Add to Cart

MONO-FACIAL MODULE RS2-350~375M-E3

P-Type /Positive power tolerance of 0~+3%/Max module efficiency 20.59%

Suitable for ground power plants and distributed projects

Advanced module technology delivers superior module efficiency

·Gallium-doped Wafer·Non destructive cutting ·MBB half-cut

Excellent power generation performance

·Excellent IAM and Weak light response ·Low temperature ratings

·0.55% linear Power decline

High module quality ensures long-term reliability

·Strict selected material ·Advanced technology ·Leading standard

Ultra-hydrophilic self-cleaning coating techniques

Electrical Characteristics STC	RS2-350M-E3	RS2-355M-E3	RS2-360M-E3	RS2-365M-E3	RS2-370M-E3	RS2-375M-E3
Maximum Power (Pmax)	350W	355W	360W	365W	370W	375W
Power Tolerance	0~+5W	0~+5W	0~+5W	0~+5W	0~+5W	0~+5W
Module Efficiency	19.21%	19.49%	19.76%	20.04%	20.31%	20.59%
Maximum Power Current (Imp)	10.58A	10.64A	10.70A	10.76A	10.82A	10.89A
Maximum Power Voltage (Vmp)	33.00V	33.30V	33.60V	33.90V	34.20V	34.40V
Short Circuit Current (Isc)	11.01A	11.09A	11.17A	11.25A	11.32A	11.41A
Open Circuit Voltage (Voc)	40.50V	40.70V	40.90V	41.10V	41.30V	41.50V

Values at Standard Test Conditions STC(AM1.5, Iradiance 1000W/m.Cel Temperature 25°℃)

Electrical Characteristics NOCT	RS2-350M-E3	RS2-355M-E3	RS2-360M-E3	RS2-365M-E3	RS2-370M-E3	RS2-375M-E3
Maximum Power (Pmax)	263W	267W	271W	275W	279W	283W
Maximum Power Current (lmp)	8.48A	8.54A	8.60A	8.65A	8.71A	8.77A
Maximum Power Voltage (Vmp)	31.10V	31.30V	31.50V	31.80V	32.00V	32.20V
Short Circuit Current (Isc)	8.96A	9.00A	9.06A	9.10A	9.16A	9.23A
Open Circuit Voltage (Voc)	37.70V	38.00V	38.30V	38.60V	38.90V	39.10V

NOCT, lrradiance of 800W/m² AM1.5,Ambient Temperature 20°C, wind Speed 1m/s.
